The structural composition of an electron wire

Electronic wire is mainly used for the connection between the internal circuit of electronic equipment, it can transmit current or signal in the electrical equipment, the normal use of electronic equipment can not leave the electronic wire! At present, China's mainstream electronic wire has three standards: 3C standard, UL standard and VDE standard, the internal conductor of electronic wire is generally tinned copper or bare copper. Do you know the structure of an electron wire? Let's get to know:



1. The conductor is tinned soft copper wire with American wire gauge 14-30AWG, electronic wire and electrical soft copper wire with cross-sectional area of 0.3-2.0 mm2. There are three conductor methods: stranded conductor, OS-1(TCW) conductor, solid conductor.



2, the barrier layer using horizontal coil or woven ф 0.1mm and above wire diameter tinned soft copper wire, to improve the cable anti-disturbance, anti-noise ability.



3, the jacket material mainly adopts heat-resistant PVC jacket material imported from Japan.



4, insulation materials are mainly imported from Japan with high function heat-resistant PVC insulation material. (Soft, semi-rigid, rigid three categories)
